Leisure

Marine
and Caravan.

Sealed deep-cycle AGM for leisure banks. Non-spillable, vibration-resistant, built for daily cycling in marine, caravan and motorhome installations.

Duty Cycle

Dual-Purpose Cycling and Cranking.

Marine, caravan, motorhome and RV installations run cranking duty and onboard cycling from a single battery. The right answer is a sealed, non-spillable deep-cycle AGM that handles vibration, repeated discharge and partial state-of-charge rest.

  • Applicable Equipment

    Marine auxiliary, caravan house batteries, motorhome leisure banks, trolling motors, dual-purpose start and cycle duty.

    Onboard banks that carry both the engine start load and the daily cycling load. Vibration tolerance and partial state-of-charge resilience matter as much as raw capacity.

  • Applicable Series

    DC Series (Deep-Cycle AGM) handles dual-purpose duty. Dedicated leisure range in development.

    Thick-plate deep-cycle AGM tolerates the cycling load while delivering the cranking current for inboard and outboard auxiliary starts. Sized across 35 to 260 Ah at 12V.

    Recommended ATB models: DC12-55 DC12-85 DC12-105 DC12-200 DC12-260

  • Construction

    Sealed VRLA, non-spillable, multi-orientation install, no topping up or venting required.

    Built for marine and mobile installs where vibration, tilt and sealed enclosures rule out flooded designs. Glass-mat separator and recombinant chemistry handle the lifestyle.

Status note: A dedicated dual-purpose leisure AGM line is in development. Until release, the DC deep-cycle range covers most leisure duty cycles. Contact sales for application-specific guidance.

AGM — Absorbed Glass Mat

Lead-Acid VRLA

The DC Series deep-cycle AGM provides a deep-discharge path for leisure duty. 6V, 8V and 12V formats from 35Ah to 400Ah.

Leisure

DC Series for Leisure Duty

Sealed deep-cycle AGM with high-density active paste and heavy positive grids for marine, caravan and motorhome cycling.

DC Series — Deep-Cycle AGM

Deep CycleMaintenance-FreeAny OrientationSealed VRLA

Deep-cycle AGM for marine auxiliary banks, caravan and motorhome house batteries, trolling motors and dual-purpose cycling duty. Heavy positive grids and high-density active paste support repeated deep discharge between charges.

Sealed VRLA construction with gas-recombinant technology. Non-spillable, vibration-resistant and installable in multiple orientations. No topping up and no off-gassing requirement.

Handles up to 80 percent DoD with plate thickness, grid alloy and active paste density tuned for cycling rather than cranking. Dedicated dual-purpose leisure range in development.

ATB AGM DC12-105 deep-cycle battery
DC series specifications
ModelVoltageC20 (Ah)C5 (Ah)C3 (Ah)Dimensions (mm)WeightTerminal
ATB AGM DC6-2206V220Ah187Ah166.8Ah307 × 169 × 22030 kgM8
ATB AGM DC6-2246V224Ah190.5Ah169.8Ah260 × 180 × 24630.5 kgM8
ATB AGM DC6-2456V245Ah208.5Ah186Ah243 × 188 × 27533.5 kgM8
ATB AGM DC6-2506V250Ah212.5Ah189.6Ah260 × 180 × 26934.5 kgM8
ATB AGM DC6-3356V335Ah285Ah254.1Ah296 × 178 × 34647 kgDT
ATB AGM DC6-4006V400Ah340Ah303Ah296 × 178 × 40556 kgDT
ATB AGM DC8-1808V180Ah153Ah136.5Ah260 × 182 × 26734 kgM8
ATB AGM DC8-2008V190Ah161.5Ah144Ah262 × 182 × 27737.5 kgM8
ATB AGM DC12-3512V35Ah29.8Ah26.5Ah196 × 131 × 16310.2 kgM6
ATB AGM DC12-5512V55Ah46.8Ah41.7Ah230 × 138 × 21016.7 kgM6
ATB AGM DC12-8512V85Ah72.5Ah64.5Ah260 × 168 × 21125 kgM8
ATB AGM DC12-10512V105Ah89.5Ah79.8Ah307 × 168 × 21130 kgM8
ATB AGM DC12-12512V115Ah98Ah87.3Ah332 × 175 × 21532.5 kgM8
ATB AGM DC12-20012V200Ah170Ah151.8Ah522 × 240 × 21861 kgM8
ATB AGM DC12-26012V260Ah221Ah197.1Ah520 × 268 × 22075 kgLT
ATB AGM DC12-35 batteryDC12-35
ATB AGM DC12-85 batteryDC12-85
ATB AGM DC12-105 batteryDC12-105
ATB AGM DC12-105 batteryDC12-105
ATB AGM DC12-260 batteryDC12-260
Golf cart on resort pathway
Resort and Grounds
Quiet Runtime. Every Shift.

DC Series powers Club Car, EZGO, and Yamaha carts on eighteen-hole courses and resort grounds.

Boat at coastal sunset
House Loads. Sunrise to Sunset.
Hot Summer. Cold Start. Ready.

DC Series absorbs the thermal cycling of marine and caravan service without acid stratification.

Need specifications or a quote for this application?

Talk to Our Team
