AGM — Absorbed Glass Mat
Lead-Acid VRLALead-acid VRLA in its most versatile form. Covers automotive start-stop, motive deep-cycle and standby. Includes a lead-carbon LC variant for partial state-of-charge and solar self-consumption duty. Every model listed below is live in the ATB range.
Start-Stop AGM
Start-stop AGM fitted to European LN1 to LN6 sizes. Lead-carbon plate technology for partial state-of-charge duty.
SSL Series — Start-Stop AGM
AGM for start-stop vehicles with idle-off, regenerative braking and frequent engine restarts. Lead-carbon plate technology delivers three times the cycle life of standard SLI, with strong charge acceptance and cold cranking in partial state-of-charge conditions.
European LN1 to LN6 fitment. Tested to EN 50342 with over 400 endurance cycles and 8,000 micro-hybrid cycles.
| Model | Voltage | Group Size | C20 (Ah) | CCA (A, EN) | RC (min, 25A) | Dimensions (mm) | Weight |
|---|---|---|---|---|---|---|---|
| ATB AGM SSL1 | 12V | 140R/H4 | 50Ah | 570 A | 80 min | 207 × 175 × 190 | 15.5 kg |
| ATB AGM SSL2 | 12V | 47/H5 | 60Ah | 660 A | 100 min | 242 × 175 × 190 | 18.5 kg |
| ATB AGM SSL3 | 12V | 48/H6 | 70Ah | 720 A | 120 min | 278 × 175 × 190 | 21 kg |
| ATB AGM SSL4 | 12V | 94R/H7 | 80Ah | 800 A | 140 min | 315 × 175 × 190 | 24 kg |
| ATB AGM SSL5 | 12V | 49/H8 | 92Ah | 850 A | 160 min | 353 × 175 × 190 | 26.5 kg |
| ATB AGM SSL6 | 12V | 95R/H9 | 105Ah | 950 A | 190 min | 394 × 175 × 190 | 30 kg |
SSL-1
SSL-2
SSL-3
SSL-4
SSL-5GP Series — General Purpose VRLA
General-purpose sealed lead acid AGM for UPS, security panels, emergency lighting, medical devices, access control and standby duty. Three to five year design life in float service at 25 degrees Celsius.
Sealed valve-regulated construction, maintenance-free and installable in multiple orientations. Low self-discharge and stable float voltage. Tested to IEC 60896-21 and IEC 60896-22.
Covers 4.5 Ah through 200 Ah across 6V and 12V formats. For longer design life or front-terminal access, specify the FT series.
| Model | Voltage | C20 (Ah) | C10 (Ah) | C5 (Ah) | Dimensions (mm) | Weight | Terminal |
|---|---|---|---|---|---|---|---|
| ATB AGM GP12-1.2 | 12V | 1.3Ah | 1.15Ah | 1.1Ah | 97 × 43 × 51.5 | 0.55 kg | F1 |
| ATB AGM GP12-2.3 | 12V | 2.3Ah | 2Ah | 1.95Ah | 97 × 43 × 51 | 0.55 kg | F1 |
| ATB AGM GP12-5 | 12V | 5Ah | 4.7Ah | 4.3Ah | 90 × 70 × 100 | 1.56 kg | F1 |
| ATB AGM GP12-7 | 12V | 7Ah | 6.6Ah | 6Ah | 151 × 65 × 94 | 2.05 kg | F1 |
| ATB AGM GP12-9 | 12V | 9Ah | 8.5Ah | 7.7Ah | 151 × 65 × 94 | 2.43 kg | F2 |
| ATB AGM GP12-12 | 12V | 12Ah | 11.4Ah | 10.2Ah | 151 × 98.5 × 95 | 3.45 kg | F2 |
| ATB AGM GP12-18 | 12V | 18Ah | 16.2Ah | 14.5Ah | 151 × 98 × 95 | 3.45 kg | M5 |
| ATB AGM GP12-26 | 12V | 26Ah | 24Ah | 22.5Ah | 175 × 165 × 127 | 7.35 kg | M5 |
| ATB AGM GP12-35 | 12V | 35Ah | 33Ah | 28.5Ah | 196 × 131 × 155 | 10 kg | M6 |
| ATB AGM GP12-40 | 12V | 42Ah | 40Ah | 34Ah | 197 × 166 × 170 | 11.7 kg | M6 |
| ATB AGM GP12-55 | 12V | 58Ah | 55Ah | 48Ah | 230 × 138 × 210 | 16.7 kg | M6 |
| ATB AGM GP12-70 | 12V | 68Ah | 65Ah | 55Ah | 348 × 167 × 177 | 20 kg | M6 |
| ATB AGM GP12-100 | 12V | 77Ah | 75Ah | 67.5Ah | 260 × 168 × 211 | 21.7 kg | M6 |
| ATB AGM GP12-120 | 12V | 120Ah | 111Ah | 96Ah | 332 × 175 × 215 | 32 kg | M8 |
| ATB AGM GP12-150 | 12V | 156Ah | 150Ah | 134Ah | 482 × 170 × 240 | 44.5 kg | M8 |
| ATB AGM GP12-200 | 12V | 210Ah | 200Ah | 186Ah | 522 × 240 × 218 | 58 kg | M8 |
| ATB AGM GP12-200 | 12V | 270Ah | 260Ah | 225Ah | 522 × 240 × 218 | 58 kg | M8 |
GP12-7
GP12-18
GP12-55
GP12-100
GP12-200DC Series — Deep-Cycle AGM
Deep-cycle AGM for floor scrubbers, scissor lifts, golf cars, mobility equipment and light industrial motive power. Heavy positive grids and high-density active paste support repeated deep discharge under shift duty.
Sealed VRLA construction with gas-recombinant technology. Non-spillable and installable in multiple orientations. No topping up and no off-gassing requirement.
Built for daily deep-discharge duty and partial state-of-charge rest between charges. Handles up to 80 percent DoD under motive workload, with plate thickness, grid alloy and active paste density tuned for cycling rather than cranking.
| Model | Voltage | C20 (Ah) | C5 (Ah) | C3 (Ah) | Dimensions (mm) | Weight | Terminal |
|---|---|---|---|---|---|---|---|
| ATB AGM DC6-224 | 6V | 224Ah | 179Ah | 161Ah | 260 × 180 × 248 | 30.5 kg | M8 |
| ATB AGM DC6-250 | 6V | 250Ah | 200Ah | 180Ah | 260 × 182 × 269 | 34.4 kg | M8 |
| ATB AGM DC6-335 | 6V | 335Ah | 268Ah | 241Ah | 296 × 178 × 345 | 47 kg | DT |
| ATB AGM DC6-400 | 6V | 400Ah | 320Ah | 288Ah | 296 × 178 × 405 | 56 kg | DT |
| ATB AGM DC8-200 | 8V | 200Ah | 160Ah | 144Ah | 260 × 180 × 280 | 37.4 kg | M8 |
| ATB AGM DC12-35 | 12V | 35Ah | 28Ah | 25Ah | 195 × 131 × 155 | 9.9 kg | M6 |
| ATB AGM DC12-55 | 12V | 55Ah | 44Ah | 40Ah | 229 × 136 × 210 | 16.4 kg | M6 |
| ATB AGM DC12-85 | 12V | 85Ah | 68Ah | 61Ah | 260 × 168 × 211 | 25 kg | M8 |
| ATB AGM DC12-105 | 12V | 105Ah | 84Ah | 76Ah | 306 × 169 × 216 | 28 kg | M8 |
| ATB AGM DC12-210 | 12V | 210Ah | 168Ah | 151Ah | 522 × 240 × 219 | 58 kg | M8 |
| ATB AGM DC12-260 | 12V | 260Ah | 208Ah | 187Ah | 520 × 268 × 220 | 73.5 kg | LT |
DC12-35
DC12-85
DC12-105
DC12-210
DC12-260Need to match a specific floor scrubber, scissor lift, MEWP or golf car to a DC Series battery? Use the equipment selector on the Motive application page →
HR Series — High-Rate VRLA
High-rate sealed lead acid AGM sized for short-duration high-current UPS discharge. Ten year design life at 25 degrees Celsius in float service.
Performance rated in watts per cell at the 15-minute discharge rate to 1.67 volts per cell end-of-discharge. Pick the model by required power per string, not by amp-hour capacity.
Thin-plate construction delivers high power density for runtime windows between 5 and 30 minutes. Tested to IEC 60896-21 and IEC 60896-22.
| Model | Voltage | W/cell @15min | C20 (Ah) | C5 (Ah) | Dimensions (mm) | Weight | Terminal |
|---|---|---|---|---|---|---|---|
| ATB AGM HR12-37 | 12V | 37W | 9Ah | 7.7Ah | 151 × 65 × 94 | 2.57 kg | F1 |
| ATB AGM HR12-92 | 12V | 92W | 21.5Ah | 18.5Ah | 181 × 77 × 167 | 6.3 kg | M5 |
| ATB AGM HR12-120 | 12V | 120W | 30Ah | 26Ah | 165 × 125 × 175 | 9 kg | M5 |
| ATB AGM HR12-150 | 12V | 150W | 34Ah | 30Ah | 195 × 130 × 155 | 11 kg | M6 |
| ATB AGM HR12-250 | 12V | 250W | 57Ah | 53Ah | 229 × 138 × 210 | 18 kg | M6 |
| ATB AGM HR12-300 | 12V | 300W | 78Ah | 67Ah | 260 × 169 × 211 | 24 kg | M6 |
| ATB AGM HR12-350 | 12V | 350W | 94Ah | 80Ah | 306 × 169 × 211 | 28.5 kg | M6 |
| ATB AGM HR12-420 | 12V | 420W | 118Ah | 100Ah | 332 × 175 × 215 | 32 kg | M6 |
| ATB AGM HR12-520 | 12V | 520W | 143Ah | 134Ah | 341 × 173 × 282 | 42.5 kg | M6 |
HR12-37
HR12-92
HR12-150
HR12-300
HR12-520FT Series — Front Terminal
Front-terminal AGM for telecom cabinets, UPS racks and installs where front access matters. Ten year design life at 25 degrees Celsius in float service. Classified as Long Life under EUROBAT cycle class guidance.
Heavy lead-calcium grid alloy and increased active material extend service life well beyond general-purpose AGM. Front-terminal layout simplifies rack maintenance. Install, connect and inspect from the cabinet face.
Suited to 19 inch and 23 inch telecom shelves and indoor UPS cabinets. Tested to IEC 60896-21 and IEC 60896-22.
| Model | Voltage | C10 (Ah) | C20 (Ah) | C5 (Ah) | Dimensions (mm) | Weight | Terminal |
|---|---|---|---|---|---|---|---|
| ATB AGM FT12-55 | 12V | 55Ah | 60Ah | 50.8Ah | 277 × 106 × 223 | 16 kg | M6 front |
| ATB AGM FT12-75 | 12V | 75Ah | 82Ah | 69.3Ah | 562 × 114 × 188 | 27 kg | M8 front |
| ATB AGM FT12-80 | 12V | 80Ah | 87Ah | 73.9Ah | 390 × 105 × 255 | 29.3 kg | M8 front |
| ATB AGM FT12-100 | 12V | 100Ah | 109Ah | 92.4Ah | 507 × 109 × 223 | 32 kg | M8 front |
| ATB AGM FT12-125 | 12V | 125Ah | 136Ah | 115.5Ah | 550 × 105 × 315 | 44.6 kg | M8 front |
| ATB AGM FT12-150 | 12V | 150Ah | 163Ah | 138.6Ah | 569 × 110 × 290 | 47.5 kg | M8 front |
| ATB AGM FT12-170 | 12V | 170Ah | 185Ah | 157.1Ah | 561 × 125 × 316 | 52.4 kg | M8 front |
| ATB AGM FT12-180 | 12V | 180Ah | 196Ah | 166.3Ah | 561 × 125 × 316 | 55.5 kg | M8 front |
| ATB AGM FT12-200 | 12V | 200Ah | 217Ah | 184.8Ah | 561 × 125 × 316 | 61.7 kg | M8 front |
FT12-55
FT12-75
FT12-100
FT12-180LC Series — Lead Carbon AGM
AGM construction with carbon additive in the negative active material. Carbon suppresses sulfation at the negative plate under partial state-of-charge duty, delivering higher cycle life and faster charge acceptance than standard AGM under the same conditions.
Best-fit: solar self-consumption, hybrid inverter storage, rural off-grid and hot-climate standby where the pack sits at partial state-of-charge between cycles. Four 12V models from 100 Ah to 250 Ah at the C10 rate.
| Model | Voltage | C10 (Ah) | C20 (Ah) | C5 (Ah) | Dimensions (mm) | Weight | Terminal |
|---|---|---|---|---|---|---|---|
| ATB LC12-200 | 12V | 200Ah | 215Ah | 182.8Ah | 520 × 268 × 220 | 65 kg | M8 |
| ATB LC12-230 | 12V | 230Ah | 245Ah | 208.3Ah | 520 × 268 × 220 | 72 kg | M8 |
LC12-200
LC12-2302V Series — Long-Life Telecom Cells
2V VRLA AGM cells for telecom, networking, military standby, large UPS banks and utility applications. Capacities from 100 Ah to 3,000 Ah per cell.
Design life 10 years at 25 degrees Celsius per manufacturer test. Tested to Eurobat IEC 60896-21 and IEC 60896-22 for stationary VRLA performance, measured to the standard's 80 percent of rated capacity end-of-life threshold.
| Model | Voltage | C20 (Ah) | C10 (Ah) | C100 (Ah) | Dimensions (mm) | Weight | Terminal |
|---|---|---|---|---|---|---|---|
| ATB AGM 2V-100 | 2V | 110Ah | 100Ah | 121.77Ah | 171 × 72 × 204 | 5.6 kg | M8 |
| ATB AGM 2V-200 | 2V | 200Ah | 184Ah | 220Ah | 170 × 106 × 332 | 12.5 kg | M8 |
| ATB AGM 2V-300 | 2V | 300Ah | 276Ah | 330Ah | 172 × 151 × 319 | 18 kg | M8 |
| ATB AGM 2V-600 | 2V | 600Ah | 552Ah | 660Ah | 285 × 171 × 330 | 36.5 kg | M8 |
| ATB AGM 2V-1500 | 2V | 2150Ah | 2000Ah | 2380.05Ah | 476 × 337 × 330 | 111 kg | M8 |
2V-100
2V-500
2V-1000
2V-1500
2V-3000All specifications nominal at 25°C. Weights and dimensions typical. Blank fields are pending vendor confirmation. LC capacities published at the C10 rate. Full datasheets and product drawings on request.
