Motive

Equipment
That Moves.

MEWPs, floorcare, golf, material handling. AGM deep-cycle and LiFePO₄ monobloc paths. Fifteen lithium SKUs sized to common lead-acid footprints for direct upgrade.

Duty Cycle

Equipment That Moves.

Motive applications run long operating shifts, tolerate deep discharge and recharge on the operator's schedule. Two chemistries cover this duty. DC Series AGM for the proven lead-acid path. Lithium Motive monoblocs for operators ready to move to LiFePO₄.

Applicable Equipment

MEWPs, scissor lifts, boom lifts, floor scrubbers, sweepers, golf cars, UTVs, AGV/AMR, material handling.

Applicable Series

DC Series (AGM, 35Ah to 400Ah, 6V/8V/12V). Lithium Motive Series (LiFePO₄ monobloc across 24V, 36V, 48V and 72V).

Duty Pattern

Daily deep-discharge to 80 percent DoD (AGM). Opportunity charging between shifts. Partial state-of-charge rest.

Equipment Selector

Find the ATB DC Match for Your Equipment.

Pick your equipment type, manufacturer and model. The matching ATB AGM DC Series battery appears below with its core specifications.

Your ATB match will appear here once you pick an equipment model.

For reference purposes only. Charger compatibility and charge algorithm must be verified before installation. AGM batteries require an AGM-compatible charge profile. Tray fit, terminal orientation and cable spec should be confirmed per application.

AGM — Absorbed Glass Mat

Lead-Acid VRLA

DC Series deep-cycle AGM for motive duty. 6V, 8V and 12V formats from 35Ah to 400Ah. Built for daily deep-discharge duty and partial state-of-charge rest.

Motive

Deep-Cycle AGM

Heavy plates, high-density paste, tuned for cycling not cranking.

DC Series — Deep-Cycle AGM

Deep CycleMaintenance-FreeAny OrientationSealed VRLA

Deep-cycle AGM for floor scrubbers, scissor lifts, golf cars, mobility equipment and light industrial motive power. Heavy positive grids and high-density active paste support repeated deep discharge under shift duty.

Sealed VRLA construction with gas-recombinant technology. Non-spillable and installable in multiple orientations. No topping up and no off-gassing requirement.

Built for daily deep-discharge duty and partial state-of-charge rest between charges. Handles up to 80 percent DoD under motive workload, with plate thickness, grid alloy and active paste density tuned for cycling rather than cranking.

DC series specifications
Model	Voltage	C20 (Ah)	C5 (Ah)	C3 (Ah)	Dimensions (mm)	Weight	Terminal
ATB AGM DC6-224	6V	224Ah	179Ah	161Ah	260 × 180 × 248	30.5 kg	M8
ATB AGM DC6-250	6V	250Ah	200Ah	180Ah	260 × 182 × 269	34.4 kg	M8
ATB AGM DC6-335	6V	335Ah	268Ah	241Ah	296 × 178 × 345	47 kg	DT
ATB AGM DC6-400	6V	400Ah	320Ah	288Ah	296 × 178 × 405	56 kg	DT
ATB AGM DC8-200	8V	200Ah	160Ah	144Ah	260 × 180 × 280	37.4 kg	M8
ATB AGM DC12-35	12V	35Ah	28Ah	25Ah	195 × 131 × 155	9.9 kg	M6
ATB AGM DC12-55	12V	55Ah	44Ah	40Ah	229 × 136 × 210	16.4 kg	M6
ATB AGM DC12-85	12V	85Ah	68Ah	61Ah	260 × 168 × 211	25 kg	M8
ATB AGM DC12-105	12V	105Ah	84Ah	76Ah	332 × 175 × 215	30 kg	M8
ATB AGM DC12-210	12V	210Ah	168Ah	151Ah	522 × 240 × 219	58 kg	M8
ATB AGM DC12-260	12V	260Ah	208Ah	187Ah	520 × 268 × 220	73.5 kg	LT

DC12-35

DC12-85

DC12-105

DC12-210

DC12-260

Vertical mast lift against industrial wall

MEWP and Aerial Work

Vertical Lift. Long Runtime.

DC Series and Lithium Motive cover scissor, boom, and vertical mast duty with sealed AGM and drop-in LiFePO₄ options.

Lithium Motive — LiFePO₄ Monoblocs

LiFePO₄

Monobloc LiFePO₄ sized to common lead-acid footprints. Direct upgrade path for operators moving from AGM to lithium. Ranges cover floorcare, MEWP and golf duty profiles.

Lithium Motive motive lithium specifications
Model	Nominal V	Capacity (Ah)	Energy (kWh)	Dimensions (mm)	Best-Fit	Project ID	Datasheet
ATB-LFP-M-124	25.6V	105 Ah	2.69 kWh	465 × 170 × 270	F / M	DQ-25.6-105	On Request
ATB-LFP-M-064	25.76V	150 Ah	3.86 kWh	465 × 250 × 270	F / M	DQ-25.76-150	On Request
ATB-LFP-M-067	25.76V	206 Ah	5.31 kWh	465 × 250 × 270	F	DQ-25.76-206	On Request
ATB-LFP-M-M313	25.76V	206 Ah	5.31 kWh	455 × 214 × 270	M	DQ-25.76-206	On Request
ATB-LFP-M-A101	25.6V	230 Ah	5.89 kWh	606 × 347 × 259	F / M	DQ-25.6-230	On Request
ATB-LFP-M-M256	25.76V	302 Ah	7.78 kWh	672 × 215 × 585	F	DQ-25.76-302	On Request
ATB-LFP-M-564	38.4V	280 Ah	10.75 kWh	588 × 536 × 388	F	DQ-38.4-280	On Request
ATB-LFP-M-Z294	38.4V	280 Ah	10.75 kWh	588 × 536 × 388	F	DQ-38.4-280	On Request
ATB-LFP-M-M310	38.64V	302 Ah	11.67 kWh	588 × 536 × 388	F	DQ-38.64-302	On Request
ATB-LFP-M-B647	51.2V	105 Ah	5.38 kWh	455 × 320 × 265	G	DQ-51.2-105	On Request
ATB-LFP-M-B396	51.52V	150 Ah	7.73 kWh	830 × 260 × 535	G	DQ-51.52-150	On Request
ATB-LFP-M-B292	51.2V	210 Ah	10.75 kWh	807 × 340 × 480	G	DQ-51.2-210	On Request
ATB-LFP-M-B159	51.2V	230 Ah	11.78 kWh	894 × 333 × 380	M / G	DQ-51.2-230	On Request
ATB-LFP-M-B150	51.2V	304 Ah	15.56 kWh	990 × 400 × 300	M	DQ-51.2-304	On Request
ATB-LFP-M-C025	76.8V	105 Ah	8.06 kWh	486 × 460 × 328	G	DQ-76.8-105	On Request
ATB-LFP-M-C398	77.28V	173 Ah	13.37 kWh	894 × 333 × 380	G	DQ-77.28-173	On Request
ATB-LFP-M-C207	76.8V	210 Ah	16.13 kWh	786 × 402 × 571	G	DQ-76.8-210	On Request

ATB-LFP-M-064 LiFePO4 motive monobloc battery

Fleet Deployment

Drop-In Upgrade to Lithium.

Lithium Motive monoblocs match common lead-acid footprints across 24, 36, 48, and 72 volt systems.

Need specifications or a quote for this application?

Talk to Our Team
