Start-Stop AGM
for idle-off and
micro-hybrid duty.
Lead-carbon AGM for vehicles with idle-stop, regenerative braking and frequent engine restarts. European LN1 to LN6 fitment. Tested to EN 50342 for endurance and micro-hybrid cycles.
Lead-carbon negatives
Carbon additive in the negative active material suppresses sulfation under partial state-of-charge. Restart current stays strong over thousands of micro-cycles.
EN 50342 verified
Over 400 endurance cycles and 8,000 micro-hybrid cycles per the European start-stop test profile.
European LN fitment
LN1 to LN6 case sizes: 175 mm width, 190 mm height, length varies. Auto-post terminal with B13 hold-down profile.
Sealed AGM
Valve-regulated, gas-recombinant, non-spillable. Multi-orientation install. No topping up, no acid stratification under heavy cycling.
Built for the stop. Built for the restart.
Standard SLI batteries lose plate capacity under repeated partial state-of-charge. SSL plates run a calcium-tin grid with carbon-enhanced negatives that hold charge acceptance over thousands of stop-start events. Three times the cycle life of standard SLI under EN 50342 hybrid testing.
SSL Series — Start-Stop AGM Lineup
AUTO · MICRO-HYBRID · LN-FITSix AGM start-stop batteries on a 175 mm × 190 mm footprint. CCA from 570 to 950 A. RC from 80 to 190 minutes. Auto-post terminals on every model.
| Model | V | Group | C20 | CCA (EN) | RC (25A) | L × W × H (mm) | Weight |
|---|---|---|---|---|---|---|---|
| ATB AGM SSL1 | 12V | 140R/H4 | 50 Ah | 570 A | 80 min | 207 × 175 × 190 | 15.8 kg |
| ATB AGM SSL2 | 12V | 47/H5 | 60 Ah | 660 A | 100 min | 242 × 175 × 190 | 18.5 kg |
| ATB AGM SSL3 | 12V | 48/H6 | 70 Ah | 720 A | 120 min | 278 × 175 × 190 | 21 kg |
| ATB AGM SSL4 | 12V | 94R/H7 | 80 Ah | 800 A | 140 min | 315 × 175 × 190 | 24 kg |
| ATB AGM SSL5 | 12V | 49/H8 | 92 Ah | 850 A | 160 min | 353 × 175 × 190 | 26.8 kg |
| ATB AGM SSL6 | 12V | 95R/H9 | 105 Ah | 950 A | 190 min | 394 × 175 × 190 | 29.7 kg |
SSL-1
SSL-2
SSL-3
SSL-4Representative sizes shown. Full SSL Series range and datasheets at atbpower.com.
Where SSL Fits — Vehicle Programs
PASSENGER · LIGHT-COMMERCIALSSL replaces standard SLI on vehicles with automatic engine stop, restart and energy recovery. The carbon-enhanced negative plate handles the partial state-of-charge that flattens conventional flooded SLI within 18 to 24 months.
Idle-Stop Vehicles
Cars that shut the engine at every stop light. Each restart is a heavy load on the battery while the alternator is off. SSL holds restart current stable for the warranty period.
Regenerative Braking
Brake-recovery charge currents are high and irregular. SSL's lead-carbon plates accept charge faster than standard SLI without grid corrosion.
Light-Hybrid Systems
48 V mild-hybrids retain a 12 V SSL for accessory loads. Frequent shallow cycling per drive cycle is the design duty.
Frequent Short Trips
Urban delivery, courier, taxi, fleet. High restart count, low time on alternator. SSL outlasts SLI by a factor of three under this profile.
Factory & Compliance
Factory
- ISO 9001 Quality system
- ISO 14001 Environment
- ISO 45001 Occupational H&S
Product
- EN 50342 Start-stop endurance
- IEC 60095-1 Lead-acid starter
- UN 38.3 Transport
Cycling
- >400 cycles EN endurance
- 8,000 cycles Micro-hybrid
- 3× SLI Cycle life
SSL ships with EN 50342 test reports on request. Vehicle fitment guides for European LN sizing available via atbpower.com. Datasheets, applications support and OEM cross-references at info@atbpower.com.
